Alloy Steel AISI 8740 Fasteners
India’s Top Manufacturer & Supplier of high-class ASTM A320 Alloy Steel AISI 8740 Fastener / ASTM A574 AS AISI-SAE 8740 Fasteners
Alloy Steel AISI 8740 Fasteners finds its uses in applications where strength, toughness, and wear resistance are of prime importance. At Multinox Inc, we stock high-strength forged AISI 8740 Fasteners in varieties of AISI 8740 Bolts, AISI 8740 screws, AISI 8740 nuts, AISI 8740 washers & other fasteners with respect to various International standard and specifications.
Alloy Steel AISI 8740 Bolts, AISI 8740 Nuts, ASTM A320 AISI 8740 Screws, UNS G87400 Alloy Steel Stud Bolts Fasteners, AISI 8740 Washers, SAE 8740 Threaded Rod Exporter & Stockists
Grade 8740 AISI Shoulder Nuts, AISI 8740 Nut, DIN 1.6546 Alloy Steel Fasteners, ASTM A574 8740 AISI Bolt, AISI 8740 Bolt Nuts, AISI 8740 Screw & Nuts Suppliers and Exporters in Mumbai, India.
AISI-SAE 8740 is a nickel-chromium-molybdenum low-alloy steel with tensile strength, yield strength, fatigue resistance, toughness, and wear resistance properties. We pride ourselves on offering a range of AISI 8740 Fasteners to various industries such as Aerospace, Defense, Automotive, Petrochemical, Waste Processing, Marine and Pharmaceutical and many other sectors.
Searching for manufacturer and supplier of custom fasteners created with Alloy Steel Grade 8740? Since more than 20 years, We Multinox Inc have provided cost-effective and quality with timely solutions for specialty fastener applications to a diverse range of industries. Please send an inquiry or do call us today to request a free quote!
Our Fasteners Products:
Specifications
| Standard | ASTM A193, ASTM A194 / ASME SA193, SA194 GR, IS, BS |
| Specification | IS, BS, ASTM |
| Size | M 02 to M 160 |
| Length | UPTO 5 METERS |
| Grade | B 6, B 7/ B 7M, B 16, 2, 2HM, 2H, GR 6, B 7, B 7M |
| Type | Bolts, nuts, Washers, Anchor Fasteners, Stud Bolts, Eye Bolt, Stud, Threaded Rod, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, etc. |
Chemical Composition
Fe
96.595 – 97.72
Iron
Mn
0.750 – 1.00
Manganese
Ni
0.400 – 0.700
Nickel
Cr
0.400 – 0.600
Chromium
C
0.380 – 0.430
Carbon
Mo
0.200 – 0.300
Molybdenum
Si
0.150 – 0.300
Silicon
S
0.0400
Sulfur
P
0.0350
Phosphorus
Equivalent Grades
STANDARD
AISI 8740
Standard
WERKSTOFF NR.
1.6546
Werkstoff Number
UNS
G87400
UNS
Physical Properties
7.85 g/cm³ / 0.284 lb/in³
Density
Thermal Properties
46.6 W/mK / 323 BTU in/hr.ft².°F
Thermal Conductivity
Mechanical Properties
695 MPa / 101000 psi
Tensile Strength
415 MPa / 60200 psi
Yield Strength
190-210 GPa / 27557-30458 ksi
Elastic Modulus
140 GPa / 20300 ksi
Bulk Modulus
80 GPa / 11600 ksi
Shear Modulus
0.27-0.30
Poisson’s Ratio
22.20%
Elongation at Break (50mm)
41 J / 30.2 ft.lb
Izod Impact
201
Hardness, Brinell
223
Hardness, Knoop
93
Hardness, Rockwell B
13
Hardness, Rockwell B (below normal HRC range)
211
Hardness, Vickers
65
Machinability
Availability of Alloy Steel AISI 8740 Fasteners
| Alloy Steel AISI 8740 Fasteners | AISI 8740 Alloy Bolts |
| Steel AISI 8740 Nuts | UNS G87400 Screws |
| Alloy AISI 8740 Sockets | AISI 8740 Steel Studs |
| AISI 8740 Alloy Steel Hex Head Bolts | Alloy Hex AISI 8740 Set Screw |
| UNS G87400 Socket Screw | AISI 8740 Alloy Steel Cap Screw |
| AISI 8740 Alloy Machine Screw | Steel AISI 8740 Socket Head Cap Screw |
| Alloy Steel AISI 8740 Allen Cap screw | UNS G87400 Pan Head Screw |
| AISI 8740 Steel Wing Screw | AISI 8740 Alloy Steel Washers |
| UNS G87400 Spring Washers | Steel AISI 8740 Anchor Bolt |
| Alloy Steel AISI 8740 Structural Bolts | AISI 8740 Alloy Marine Anchor Bolt |
| Steel AISI 8740 Hex Set Screw | UNS G87400 Hexagon Nut |
| Alloy Steel AISI 8740 Hex Nut | AISI 8740 Steel Hex Coupling Nut |
| Alloy Steel AISI 8740 Hex Domed Cap Nuts | Alloy AISI 8740 Square Nut |
| UNS G87400 Stud Bolts | AISI 8740 Alloy Socket Hexagon Head Screw Anchor Bolt |
| Alloy Steel AISI 8740 U-Bolts | AISI 8740 Steel J Bolts |
| Alloy Mushroom Head Square Neck Bolts | AISI 8740 Alloy Steel T-Head Bolts |
| Steel AISI 8740 Wing Screw | UNS G87400 Eye Bolt |
| Alloy AISI 8740 Foundation Bolts |
Available Grades of Alloy Steel Fasteners
| Alloy Steel AISI 4130 Fasteners | Alloy Steel AISI 4140 Fasteners |
| Alloy Steel AISI 4340 Fasteners | Alloy Steel AISI 8620 Fasteners |
| Alloy Steel AISI 8740 Fasteners | Alloy Steel ASTM A193 Grade B7 Fasteners |
| Alloy Steel ASTM A193 Grade BM7 Fasteners | Alloy Steel ASTM A193 Grade B16 Fasteners |
| Alloy Steel ASTM A194 Grade 4 Fasteners | Alloy Steel ASTM A194 Grade 7 Fasteners |
| Alloy Steel ASTM A194 Grade 7M Fasteners | Alloy Steel ASTM A194 Grade 16 Fasteners |
| Alloy Steel ASTM A320 Grade L7 Fasteners | Alloy Steel SAE J429 Grade 8 Fasteners |
Available Types of Alloy Steel AISI 8740 Nuts
| AISI 8740 Alloy Steel Hex Nuts | UNS G87400 Dome Nuts | Alloy AISI 8740 Hex Machine Screw Nuts |
| AISI 8740 Alloy Steel Hex Lock Nuts | Nylon Insert UNS G87400 Hex Jam Nuts | Alloy AISI 8740 Hex Jam Nylon Lock Nuts |
| AISI 8740 Alloy Steel Heavy Hex Nuts | UNS G87400 Wing Nuts | Alloy AISI 8740 Cap Nuts |
| AISI 8740 Alloy Steel Acorn Nuts | UNS G87400 Square Nuts | Alloy AISI 8740 K-Lock Nuts |
| AISI 8740 Alloy Steel Prevailing Torque Lock Nuts | UNS G87400 Top Lock Nuts | Alloy AISI 8740 Two-Way Reversible Lock Nuts |
| AISI 8740 Alloy Steel Pin-Lock Nuts | UNS G87400 T-Nuts | Alloy AISI 8740 Coupling Nuts |
| AISI 8740 Alloy Steel T-Slot Nuts | UNS G87400 Castle Nuts | Alloy AISI 8740 Knurled Nuts |
Available Types of Steel AISI 8740 Bolt
| Alloy Steel AISI 8740 Eye Bolts | AISI 8740 Steel Allen Bolts | UNS G87400 Hex Head Bolts |
| Alloy Steel AISI 8740 Hanger Bolts | AISI 8740 Steel Carriage Bolts | UNS G87400 Jack Bolts |
| Alloy Steel AISI 8740 Square Head Bolts | AISI 8740 Steel Lag Bolts | UNS G87400 U Bolts |
| Alloy Steel AISI 8740 Elevator Bolts | AISI 8740 Steel Turned Eye Bolts | UNS G87400 Hex Flange Bolts |
| Alloy Steel AISI 8740 Structural Bolts | AISI 8740 Steel Step Bolts | UNS G87400 Square Head Machine Bolts |
| Alloy Steel AISI 8740 Plow Bolts | AISI 8740 Steel Metric Bolts | UNS G87400 Hex Tap Bolts |
| Alloy Steel AISI 8740 Hex Machine Bolts | AISI 8740 Steel Shoulder Eye Bolts | UNS G87400 Hex Bolts |
Available Types of Alloy AISI 8740 Screw
| UNS G87400 Self Drilling Screw | Steel AISI 8740 Self Tapping Screw | AISI 8740 Alloy Thread Rolling Screw |
| UNS G87400 Thread Cutting Screw | Steel AISI 8740 Machine Screw | AISI 8740 Alloy Concrete Screw |
| UNS G87400 Roofing Screw | Steel AISI 8740 Drywall Screw | AISI 8740 Alloy Particle Board Screw |
| UNS G87400 Chipboard Screw | Steel AISI 8740 Construction Screws | AISI 8740 Alloy Coach Screws |
| UNS G87400 Lag Screws | Steel AISI 8740 Wood Screw | AISI 8740 Alloy Euro Screw |
| UNS G87400 Collated Screw | Steel AISI 8740 Furniture Screw | AISI 8740 Alloy Sems Screw |
| UNS G87400 AISI 8740 Phillips Head Screw | Steel AISI 8740 Set Screws | AISI 8740 Alloy Thumb Screws |
Available Types of AISI 8740 Alloy Steel Washer
| AISI 8740 Alloy Steel Flat Washers | UNS G87400 Finishing Washers | Alloy AISI 8740 Tab Washers |
| Alloy Steel AISI 8740 Conical Washers | AISI 8740 Steel Special Washers | UNS G87400 Belleville Washers |
| UNS G87400 Bonded Sealing Washers | Steel AISI 8740 Countersunk Finishing Washers | AISI 8740 Alloy Dock Washers |
| AISI 8740 Alloy Steel Fender Washers | UNS G87400 Lock Washers | Alloy AISI 8740 Neoprene Washers |
| Alloy Steel AISI 8740 Square Bevel Washers | AISI 8740 Steel Star Washers | UNS G87400 Spring Washers |
| UNS G87400 Plain Washers | Steel AISI 8740 Hex Washers | AISI 8740 Alloy Wave Washers |
| AISI 8740 Alloy Steel Crank Washers | UNS G87400 Square Washers | Alloy AISI 8740 Star Lock Washers |
Alloy Steel AISI 8740 Fasteners Applications
| Off-Shore Oil Drilling Companies | Power Generation |
| Petrochemicals | Gas Processing |
| Specialty Chemicals | Pharmaceuticals |
| Pharmaceutical Equipment | Chemical Equipment |
| Sea Water Equipment | Heat Exchangers |
| Condensers | Pulp & Paper Industry |
Recent Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
304 SS Round Bars, 50mm OD, ASTM A276
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
SS 304 Hex Bars, 40mm A/F, Cold Drawn
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
304 SS Flat Bars, 100×20mm, Bright Finish
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
304 SS Square Bars, 40mm, Forged Grade
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
SS 304 Hollow Bars, 80mm OD × 20mm wall
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
304 SS Round Bars 25–100mm, EN 10204 3.2
Delivered in 18 days
Latest Prices of Alloy Steel Fasteners
Multinox INC offers Alloy Steel Fasteners at one of the most competitive prices in India. Request the latest Alloy Steel Fasteners Pricelist using the contact form here.
