Alloy Steel AISI 8620 Fasteners
Our Fasteners Products:
Specifications
| Standard | ASTM A193, ASTM A194 / ASME SA193, SA194 GR, IS, BS |
| Specification | IS, BS, ASTM |
| Size | M 02 to M 160 |
| Length | UPTO 5 METERS |
| Grade | B 6, B 7/ B 7M, B 16, 2, 2HM, 2H, GR 6, B 7, B 7M |
| Type | Bolts, nuts, Washers, Anchor Fasteners, Stud Bolts, Eye Bolt, Stud, Threaded Rod, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, etc. |
Chemical Composition
Fe
96.895 – 98.02
Iron
%
Mn
0.700 – 0.900
Manganese
%
Ni
0.400 – 0.700
Nickel
%
Cr
0.400 – 0.600
Chromium
%
C
0.180 – 0.230
Carbon
%
Si
0.150 – 0.350
Silicon
%
Mo
0.150 – 0.250
Molybdenum
%
S
≤ 0.0400
Sulphur
%
P
≤ 0.0350
Phosphorus
%
Equivalent Grades
AISI
8620
Standard
DIN
1.6523
Werkstoff Nr.
UNS
G86200
UNS Number
Physical Properties
7.85 g/cm³ / 0.284 lb/in³
Density
Mechanical Properties
530 MPa / 76900 psi
Tensile Strength, Ultimate
385 MPa / 55800 psi
Tensile Strength, Yield
190–210 GPa / 27557–30458 ksi
Elastic Modulus
140 GPa / 20300 ksi
Bulk Modulus
80 GPa / 11600 ksi
Shear Modulus
0.27 – 0.30
Poisson's Ratio
115 J / 84.8 ft.lb
Izod Impact
149 HB
Hardness, Brinell
169 HK
Hardness, Knoop
80 HRB
Hardness, Rockwell B
155 HV
Hardness, Vickers
65 %
Machinability
Thermal Properties
46.6 W/mK / 323 BTU in/hr.ft².°F
Thermal Conductivity
Availability of Alloy Steel AISI 8620 Fasteners
| Alloy Steel AISI 8620 Fasteners | AISI 8620 Alloy Bolts |
| Steel AISI 8620 Nuts | UNS G86200 Screws |
| Alloy AISI 8620 Sockets | AISI 8620 Steel Studs |
| AISI 8620 Alloy Steel Hex Head Bolts | Alloy Hex AISI 8620 Set Screw |
| UNS G86200 Socket Screw | AISI 8620 Alloy Steel Cap Screw |
| AISI 8620 Alloy Machine Screw | Steel AISI 8620 Socket Head Cap Screw |
| Alloy Steel AISI 8620 Allen Cap Screw | UNS G86200 Pan Head Screw |
| AISI 8620 Steel Wing Screw | AISI 8620 Alloy Steel Washers |
| UNS G86200 Spring Washers | Steel AISI 8620 Anchor Bolt |
| Alloy Steel AISI 8620 Structural Bolts | AISI 8620 Alloy Marine Anchor Bolt |
| Steel AISI 8620 Hex Set Screw | UNS G86200 Hexagon Nut |
| Alloy Steel AISI 8620 Hex Nut | AISI 8620 Steel Hex Coupling Nut |
| Alloy Steel AISI 8620 Hex Domed Cap Nuts | Alloy AISI 8620 Square Nut |
| UNS G86200 Stud Bolts | Alloy Steel AISI 8620 U-Bolts |
| AISI 8620 Steel J Bolts | Alloy Mushroom Head Square Neck Bolts |
| AISI 8620 Alloy Steel T-Head Bolts | UNS G86200 Eye Bolt |
| Alloy AISI 8620 Foundation Bolts | AISI 8620 Alloy Socket Hexagon Head Screw Anchor Bolt |
Available Grades of Alloy Steel Fasteners
| Alloy Steel AISI 4130 Fasteners | Alloy Steel AISI 4140 Fasteners | Alloy Steel AISI 4340 Fasteners |
| Alloy Steel AISI 8620 Fasteners | Alloy Steel AISI 8740 Fasteners | Alloy Steel ASTM A193 Grade B7 Fasteners |
| Alloy Steel ASTM A193 Grade BM7 Fasteners | Alloy Steel ASTM A193 Grade B16 Fasteners | Alloy Steel ASTM A194 Grade 4 Fasteners |
| Alloy Steel ASTM A194 Grade 7 Fasteners | Alloy Steel ASTM A194 Grade 7M Fasteners | Alloy Steel ASTM A194 Grade 16 Fasteners |
| Alloy Steel ASTM A320 Grade L7 Fasteners | Alloy Steel SAE J429 Grade 8 Fasteners |
Available Types of Alloy Steel AISI 8620 Nuts
| AISI 8620 Alloy Steel Hex Nuts | UNS G86200 Dome Nuts | Alloy AISI 8620 Hex Machine Screw Nuts |
| AISI 8620 Alloy Steel Hex Lock Nuts Nylon Insert | UNS G86200 Hex Jam Nuts | Alloy AISI 8620 Hex Jam Nylon Lock Nuts |
| AISI 8620 Alloy Steel Heavy Hex Nuts | UNS G86200 Wing Nuts | Alloy AISI 8620 Cap Nuts |
| AISI 8620 Alloy Steel Acorn Nuts | UNS G86200 Square Nuts | Alloy AISI 8620 K-Lock Nuts |
| AISI 8620 Alloy Steel Prevailing Torque Lock Nuts | UNS G86200 Top Lock Nuts | Alloy AISI 8620 Two-Way Reversible Lock Nuts |
| AISI 8620 Alloy Steel Pin-Lock Nuts | UNS G86200 T-Nuts | Alloy AISI 8620 Coupling Nuts |
| AISI 8620 Alloy Steel T-Slot Nuts | UNS G86200 Castle Nuts | Alloy AISI 8620 Knurled Nuts |
Available Types of Steel AISI 8620 Bolt
| Alloy Steel AISI 8620 Eye Bolts | AISI 8620 Steel Allen Bolts | UNS G86200 Hex Head Bolts |
| Alloy Steel AISI 8620 Hanger Bolts | AISI 8620 Steel Carriage Bolts | UNS G86200 Jack Bolts |
| Alloy Steel AISI 8620 Square Head Bolts | AISI 8620 Steel Lag Bolts | UNS G86200 U Bolts |
| Alloy Steel AISI 8620 Elevator Bolts | AISI 8620 Steel Turned Eye Bolts | UNS G86200 Hex Flange Bolts |
| Alloy Steel AISI 8620 Structural Bolts | AISI 8620 Steel Step Bolts | UNS G86200 Square Head Machine Bolts |
| Alloy Steel AISI 8620 Plow Bolts | AISI 8620 Steel Metric Bolts | UNS G86200 Hex Tap Bolts |
| Alloy Steel AISI 8620 Hex Machine Bolts | AISI 8620 Steel Shoulder Eye Bolts | UNS G86200 Hex Bolts |
Available Types of Alloy AISI 8620 Screw
| UNS G86200 Self Drilling Screw | Steel AISI 8620 Self Tapping Screw | AISI 8620 Alloy Thread Rolling Screw |
| UNS G86200 Thread Cutting Screw | Steel AISI 8620 Machine Screw | AISI 8620 Alloy Concrete Screw |
| UNS G86200 Roofing Screw | Steel AISI 8620 Drywall Screw | AISI 8620 Alloy Particle Board Screw |
| UNS G86200 Chipboard Screw | Steel AISI 8620 Construction Screws | AISI 8620 Alloy Coach Screws |
| UNS G86200 Lag Screws | Steel AISI 8620 Wood Screw | AISI 8620 Alloy Euro Screw |
| UNS G86200 Collated Screw | Steel AISI 8620 Furniture Screw | AISI 8620 Alloy Sems Screw |
| UNS G86200 AISI 8620 Phillips Head Screw | Steel AISI 8620 Set Screws | AISI 8620 Alloy Thumb Screws |
Available Types of AISI 8620 Alloy Steel Washer
| AISI 8620 Alloy Steel Flat Washers | UNS G86200 Finishing Washers | Alloy AISI 8620 Tab Washers |
| Alloy Steel AISI 8620 Conical Washers | AISI 8620 Steel Special Washers | UNS G86200 Belleville Washers |
| UNS G86200 Bonded Sealing Washers | Steel AISI 8620 Countersunk Finishing Washers | AISI 8620 Alloy Dock Washers |
| AISI 8620 Alloy Steel Fender Washers | UNS G86200 Lock Washers | Alloy AISI 8620 Neoprene Washers |
| Alloy Steel AISI 8620 Square Bevel Washers | AISI 8620 Steel Star Washers | UNS G86200 Spring Washers |
| UNS G86200 Plain Washers | Steel AISI 8620 Hex Washers | AISI 8620 Alloy Wave Washers |
| AISI 8620 Alloy Steel Crank Washers | UNS G86200 Square Washers | Alloy AISI 8620 Star Lock Washers |
Alloy Steel AISI 8620 Fasteners Applications
| Off-Shore Oil Drilling Companies | Power Generation | Petrochemicals |
| Gas Processing | Specialty Chemicals | Pharmaceuticals |
| Pharmaceutical Equipment | Chemical Equipment | Sea Water Equipment |
| Heat Exchangers | Condensers | Pulp & Paper Industry |
Recent Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
304 SS Round Bars, 50mm OD, ASTM A276
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
SS 304 Hex Bars, 40mm A/F, Cold Drawn
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
304 SS Flat Bars, 100×20mm, Bright Finish
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
304 SS Square Bars, 40mm, Forged Grade
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
SS 304 Hollow Bars, 80mm OD × 20mm wall
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
304 SS Round Bars 25–100mm, EN 10204 3.2
Delivered in 18 days
Latest Prices of Alloy Steel Fasteners
Multinox INC offers Alloy Steel Fasteners at one of the most competitive prices in India. Request the latest Alloy Steel Fasteners Pricelist using the contact form here.
