Incoloy 800 Pipe Supplier
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
Specifications
| Specifications | ASTM / ASME (As Per Grade) |
| Dimensions | ASTM, ASME, ANSI B36.10M, ANSI B36.19M & API |
| Seamless Pipe Size | 1/2" NB to 16" NB |
| Welded Pipe Size | 1/2" NB to 24" NB |
| EFW Pipe Size | 6" NB to 24" NB |
| Outside Diameter | 6.00 mm OD to 914.4 mm OD |
| Wall Thickness | SCH 5, SCH 10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XS, SCH XXS |
| Pipe Type | Seamless, Welded, ERW, EFW, Fabricated, LSAW |
| Form | Round, Square, Rectangular, Hydraulic |
| Length | Single Random, Double Random, Cut Length, Custom Length |
| End | Plain End, Beveled End, Threaded End |
| Surface Finish | Annealed & Pickled (AP), Bright Annealed (BA), Polished, Mill Finish |
| Testing | PMI Test, Hydrostatic Test, Ultrasonic Test, Eddy Current Test, Flattening Test, Flaring Test, Third Party Inspection |
| Marking | Specification, Grade, Size, Heat No., Manufacturer's Name or Logo |
| Packing | Plastic End Caps, Bundles, Wooden Boxes, Wooden Pallets, Export Worthy Packing |
Chemical Composition
C
0.10 Max
Carbon
Ni
30.0 – 35.0
Nickel
Cr
19.0 – 23.0
Chromium
Fe
39.5 Min
Iron
Al + Ti
0.15 – 0.60
Aluminium + Titanium
Mn
1.5 Max
Manganese
Si
1.0 Max
Silicon
Equivalent Grades
STD
Incoloy 800
Standard
W.NR
1.4876
Werkstoff No.
UNS
N08800
UNS
JIS
NCF 800
Japanese Standard
AFNOR
Z8NC32-21
French Standard
BS
NA 15
British Standard
GOST
ЭИ670
Russian Standard
EN
X10NiCrAlTi32-20
European Standard
OR
XH32T
Other Reference
Mechanical Properties
520 MPa / 75,000 Psi
Ultimate Tensile Strength
205 MPa / 30,000 Psi
Yield Strength (0.2% Offset)
30%
Elongation
Size Range
| Size (Inch) | OD (mm) | OD (Inch) | WT (mm) | WT (Inch) |
|---|---|---|---|---|
| 1/8″ | 10.3 | 0.41 | 1.73 | 0.068 |
| 1/4″ | 13.7 | 0.54 | 2.24 | 0.088 |
| 3/8″ | 17.1 | 0.68 | 2.31 | 0.091 |
| 1/2″ | 21.3 | 0.84 | 2.77 | 0.109 |
| 3/4″ | 26.7 | 1.05 | 2.87 | 0.113 |
| 1″ | 33.4 | 1.32 | 3.38 | 0.133 |
Recent Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
304 SS Round Bars, 50mm OD, ASTM A276
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
SS 304 Hex Bars, 40mm A/F, Cold Drawn
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
304 SS Flat Bars, 100×20mm, Bright Finish
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
304 SS Square Bars, 40mm, Forged Grade
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
SS 304 Hollow Bars, 80mm OD × 20mm wall
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
304 SS Round Bars 25–100mm, EN 10204 3.2
Delivered in 18 days
Availability of Incoloy Pipes
| Incoloy 800 Pipe | Incoloy 800H Pipe |
| Incoloy 800HT Pipe | Incoloy 825 Pipe |
| Incoloy 925 Pipe |
Latest Prices of Pipes
Multinox INC offers Pipes at one of the most competitive prices in India. Request the latest Pipes Pricelist using the contact form here.
