AMS 5665 Inconel 600 Round Bar Supplier
Caustic Soda Plants Swear by It — UNS N06600 Inconel 600 Round Bar from Multinox Inc, Stocked Deep and Shipped Fast Worldwide.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
JIS NCF 600 Round Bar — Diameters, Conditions & Lengths
Inconel 600 Round Bar is supplied annealed, stress-relieved or as hot finished — matched to your fabrication sequence.
| Product Name | Inconel 600 Round Bar |
| Grade | Inconel 600 / UNS N06600 / WNR 2.4816 |
| Specifications | ASTM B166 / ASME SB166 |
| Standards | ASTM, ASME, DIN, EN, BS, JIS, AISI |
| Diameter | 5 mm to 500 mm |
| Length | 100 mm to 6000 mm, Custom Cut Length |
| Finish | Black, Bright, Polished, Peeled, Centerless Ground |
| Forms | Round, Square, Hex, Flat, Rectangle, Forged, Hollow & Threaded Bar |
| Condition | Annealed, Hot Rolled, Cold Drawn, Stress Relieved |
| Inspection | PMI Test, Ultrasonic Test, Mechanical Test, Third Party Inspection |
| Mill Test Certificate | EN 10204 3.1 / 3.2 |
EN NiCr15Fe Round Bar Chemical Composition
The chromium jacket inside Inconel 600 Round Bar shields against oxidation while the nickel core fights corrosion from within.
Ni+Co
72.00 min
Nickel + Cobalt
Cr
14.00 – 17.00%
Chromium
Fe
6.00 – 10.00%
Iron
C
0.15 max
Carbon
Mn
1.00 max
Manganese
Si
0.50 max
Silicon
Cu
0.50 max
Copper
S
0.015 max
Sulphur
view Equivalent Grades — AFNOR NC15FE11M Round Bar
BS NA 13 in Britain, JIS NCF 600 in Japan, AFNOR NC15FE11M in France — Inconel 600 Round Bar is recognised on every continent..
UNS
N06600
UNS
WNR
2.4816
Werkstoff No.
EN
NiCr15Fe
European Standard
JIS
NCF 600
Japanese Standard
AFNOR
NC15FE11M
French Standard
BS
NA 13
British Standard
BS NA 13 Round Bar Mechanical Properties
The stress-relieved structure of Inconel 600 Round Bar keeps components dimensionally honest through years of thermal duty.
| Property | Value |
|---|---|
| Density | 8.47 g/cm³ |
| Melting Range | 1354 – 1413°C |
| Tensile Strength | 550 – 690 MPa |
| Yield Strength (0.2% Proof) | 240 MPa Min |
| Elongation | 35% Min |
| Hardness | ≤ 85 HRB |
| Modulus of Elasticity | 214 GPa |
Weight Chart of UNS N06600 Round Bar
| Diameter (mm) | Weight (kg/m) |
|---|---|
| 6 | 0.22 |
| 8 | 0.39 |
| 10 | 0.62 |
| 12 | 0.89 |
| 16 | 1.58 |
| 20 | 2.47 |
| 25 | 3.85 |
| 30 | 5.55 |
| 40 | 9.87 |
| 50 | 15.42 |
| 60 | 22.20 |
| 75 | 34.68 |
| 100 | 61.65 |
Weight Formula: Weight (kg/m) = (D² × 0.006165), where D is the bar diameter in millimeters.
ASME SB166 Round Bar Size Range
| Product Form | Available Size |
|---|---|
| Round Bar | 3 – 800 mm Diameter |
| Hex Bar | 2 – 100 mm A/F |
| Square Bar | 4 – 100 mm |
| Flat Bar | Thickness: 2 – 100 mm, Width: 10 – 500 mm |
| Angle Bar | 3 × 20 × 20 mm to 12 × 100 × 100 mm |
| Channel Bar | 80 × 40 mm to 150 × 75 mm |
| Rectangular Bar | 33 × 30 mm to 295 × 1066 mm |
| Hollow Bar | 32 mm OD × 16 mm ID to 250 mm OD × 200 mm ID |
| Billet | 1/2" to 495 mm Diameter |
| Length | 1–6 Meters, Custom Cut Lengths |
Recent Inconel 600 Round Bar Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
BS NA 13 Bright Round Bars, 20mm Diameter
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
UNS N06600 Peeled & Turned Bars, 48mm
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
EN NiCr15Fe Polished Round Bars, 32mm
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
JIS NCF 600 Cold Drawn Round Bars, 62mm
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
AFNOR NC15FE11M Centerless Ground Bars, 88mm
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 2.4816 Hot Rolled Black Bars, 54mm
Delivered in 18 days
Availability of Inconel 600 Round Bar
| Inconel 600 Bright Round Bar | ASTM B166 Black Round Bar |
| UNS N06600 Polished Round Bar | AMS 5665 Peeled Round Bar |
| WNR 2.4816 Turned Round Bar | BS NA 13 Ground Round Bar |
| JIS NCF 600 Cold Drawn Round Bar | ASME SB166 Hot Rolled Round Bar |
| EN NiCr15Fe Peeled & Polished Round Bar | Inconel 600 Centerless Ground Round Bar |
| AFNOR NC15FE11M Bright Bar | AMS 5665 Black Bar |
| ASTM B166 Polished Bar | UNS N06600 Peeled Bar |
| Inconel 600 Turned Bar | WNR 2.4816 Ground Bar |
| ASME SB166 Cold Drawn Bar | JIS NCF 600 Hot Rolled Bar |
| BS NA 13 Peeled & Polished Bar | AFNOR NC15FE11M Centerless Ground Bar |
JIS NCF 600 Round Bar — Latest Prices
Multinox INC offers EN NiCr15Fe Round Bars at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
