AMS 5513 Stainless Steel 304 Sheet & Plate
Available Forms & Types
Specifications
| Specifications | ASTM A240 / ASME SA240 |
| Standards | ASTM, ASME, AISI, JIS, DIN, EN, BS |
| Thickness | 0.3 mm to 120 mm |
| Width | 1000 mm, 1219 mm, 1250 mm, 1500 mm, 1800 mm, 2000 mm, 2500 mm, 3000 mm |
| Length | 2000 mm, 2440 mm, 2500 mm, 3000 mm, 5800 mm, 6000 mm & Custom Cut Length |
| Forms | Sheet, Plate, Coil, Strip, Shim Sheet, Foil, Flats, Blank (Circle), Chequered Plate, Perforated Sheet |
| Finish | 2B, BA, No.1, No.4, No.8 Mirror, 2D, Hairline, Satin, Brush, Matte, Hot Rolled (HR), Cold Rolled (CR), Pickled |
| Surface Protection | PVC Coated / Paper Interleaved |
| Edge | Mill Edge (ME), Slit Edge (SE) |
| Manufacturing Process | Hot Rolled (HR), Cold Rolled (CR) |
| Value Added Services | Cutting, Shearing, Slitting, Polishing, Bending, Laser Cutting, Water Jet Cutting |
| Inspection | PMI Testing, Ultrasonic Test, Third Party Inspection, Visual Inspection |
| Certification | EN 10204 3.1, Mill Test Certificate (MTC) |
| Packaging | Wooden Pallets, Wooden Cases, Plastic Wrapped, Export Standard Seaworthy Packing |
Chemical Composition
Ni
8.00 – 10.50
Nickel
C
0.08 Max
Carbon
Mn
2.00 Max
Manganese
P
0.045 Max
Phosphorus
S
0.030 Max
Sulfur
Si
0.75 Max
Silicon
Cr
18.00 – 20.00
Chromium
N
0.10 Max
Nitrogen
Equivalent Grades
UNS
S30400
UNS No.
JIS
SUS 304
Japanese
BS
304S31
British
SS
2332
Swedish
EN
1.4301
Euronorm No.
EN
X5CrNi18-10
Euronorm Name
BS EN
58E
British Standard
Mechanical Properties
205 MPa Min
Yield Strength
40% Min
Elongation
515 MPa Min
Tensile Strength
92 HRB Max
Hardness (HRB)
201 HB Max
Hardness (HB)
Weight Chart
| WT (in.) | Weight (kg/m²) |
|---|---|
| 3/16 | 42.18 |
| 1/4 | 56.24 |
| 3/8 | 85.07 |
| 1/2 | 113.42 |
| 5/8 | 137.80 |
| 3/4 | 165.22 |
| 7/8 | 192.64 |
| 1 | 220.06 |
| 1 1/4 | 274.90 |
| 1 1/2 | 330.44 |
| 1 3/4 | 385.98 |
| 2 | 440.82 |
| 2 1/4 | 495.66 |
| 2 1/2 | 551.20 |
| 2 3/4 | 606.04 |
| 3 | 661.58 |
Size Range
| WT (in.) | Size (in.) |
|---|---|
| 0.015 | 36 × 96 |
| 0.015 | 36 × 120 |
| 0.0178 | 36 × 96 |
| 0.0178 | 36 × 120 |
| 0.0235 | 30 × 96 |
| 0.0291 | 30 × 96 |
| 0.0355 | 30 × 96 |
| 0.0355 | 30 × 120 |
Recent Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
304 SS Round Bars, 50mm OD, ASTM A276
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
SS 304 Hex Bars, 40mm A/F, Cold Drawn
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
304 SS Flat Bars, 100×20mm, Bright Finish
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
304 SS Square Bars, 40mm, Forged Grade
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
SS 304 Hollow Bars, 80mm OD × 20mm wall
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
304 SS Round Bars 25–100mm, EN 10204 3.2
Delivered in 18 days
Availability of Stainless Steel Sheets & Plates
| Stainless Steel 304 Sheet & Plate | Stainless Steel 304L Sheet & Plate |
| Stainless Steel 316 Sheet & Plate | Stainless Steel 316L Sheet & Plate |
| Stainless Steel 316Ti Sheet & Plate | Stainless Steel 310 Sheet & Plate |
| Stainless Steel 317L Sheet & Plate | Stainless Steel 321 Sheet & Plate |
| Stainless Steel 347 Sheet & Plate | Stainless Steel 347H Sheet & Plate |
| Stainless Steel 410 Sheet & Plate | Stainless Steel 416 Sheet & Plate |
| Stainless Steel 420 Sheet & Plate | Stainless Steel 430 Sheet & Plate |
| Stainless Steel 440 Sheet & Plate | Stainless Steel 440C Sheet & Plate |
| Stainless Steel 446 Sheet & Plate | Stainless Steel 904L Sheet & Plate |
| Stainless Steel 17-4PH Sheet & Plate | Stainless Steel 15-5PH Sheet & Plate |
| SMO 254 Sheet & Plate | AL-6XN Sheet & Plate |
Latest Prices of Sheet & Plate
Multinox INC offers Sheet & Plate at one of the most competitive prices in India. Request the latest Sheet & Plate Pricelist using the contact form here.
