Aluminium 1050 Round Bar Supplier
Multinox Inc — Where Industries Source WNR 3.0255 Aluminium 1050 Round Bar with Mill Certificates and On-Time Worldwide Delivery.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
ASTM B221 Aluminium 1050 Round Bar Specifications
Aluminium 1050 Round Bar is stocked in standard diameters and cut to custom lengths, fully compliant with ASTM B221.
| Specifications | ASTM B221 / ASTM B211 / ASME SB221 |
| Standards | ASTM, ASME, EN, DIN, JIS, ISO |
| Diameter | 5 mm to 350 mm |
| Length | 1000 mm to 6000 mm, Custom Cut Length Available |
| Manufacturing Process | Extruded, Cold Drawn, Hot Rolled |
| Temper | O, H, T4, T5, T6, T651 (Depending on Alloy) |
| Surface Finish | Mill Finish, Bright Finish, Polished, Anodized |
| Forms | Round, Square, Hexagonal, Flat, Billet |
| Tolerance | As per ASTM B221 or Customer Specification |
| Available Lengths | 1 Meter, 3 Meter, 6 Meter & Cut-to-Length |
| Origin | Indian, European, Japanese & USA Mills |
| Marking | Grade, Size, Heat Number, Manufacturer's Identification |
| Packaging | Wooden Boxes, HDPE Wrapped Bundles, Plastic End Caps, Export Worthy Packing |
| Test Certificates | EN 10204 3.1, Mill Test Certificate (MTC), Third Party Inspection, PMI Test (On Request) |
| Applications | Aerospace, Marine, Automotive, Chemical Processing, Food Processing, Electrical, Construction, Oil & Gas, Engineering Industries |
UNS A91050 Aluminium 1050 Round Bar — Chemical Composition
Iron and silicon are the only notable additions in Aluminium 1050 Round Bar — keeping it pure, workable and corrosion-proof.
Al
99.50 Min
Aluminium
Si
0.25 Max
Silicon
Fe
0.40 Max
Iron
Cu
0.05 Max
Copper
Mn
0.05 Max
Manganese
Mg
0.05 Max
Magnesium
Zn
0.07 Max
Zinc
Ti
0.05 Max
Titanium
Equivalent Grades of WNR 3.0255 Aluminium 1050 Round Bar
Known as EN AW-1050A in Europe and UNS A91050 in America — Aluminium 1050 Round Bar carries universal recognition.
AA
1050
Aluminum Association
UNS
A91050
Unified Numbering System
EN
EN AW-1050A
European Standard
DIN
3.0255
German Standard
ISO
Al99.5
International Standard
JIS
A1050
Japanese Industrial Standard
EN AW-1050A Aluminium 1050 Round Bar Mechanical Properties
Aluminium 1050 Round Bar may be commercially pure, but it delivers dependable performance for electrical, chemical and food-grade applications.
| Property | Value |
|---|---|
| Density | 2.71 g/cm³ |
| Melting Point | 646 – 657°C |
| Tensile Strength | 75 – 145 MPa |
| Yield Strength | 20 MPa Min |
| Elongation | 35% |
| Hardness | Approx. 23 HB |
| Modulus of Elasticity | 69 GPa |
| Electrical Conductivity | Approximately 61% IACS |
| Thermal Conductivity | 229 W/m·K |
UNS A91050 Aluminium 1050 Round Bar Weight Chart
| Diameter (mm) | Weight (Kg/Meter) |
|---|---|
| 6 | 0.08 |
| 8 | 0.13 |
| 10 | 0.21 |
| 12 | 0.30 |
| 16 | 0.53 |
| 20 | 0.84 |
| 25 | 1.31 |
| 30 | 1.88 |
| 40 | 3.34 |
| 50 | 5.22 |
| 60 | 7.52 |
| 75 | 11.74 |
| 100 | 20.88 |
Aluminium 1050 Round Bar Size Range
| Product Form | Available Size |
|---|---|
| Round Bar | 5 mm – 350 mm Diameter |
| Square Bar | 10 mm – 100 mm |
| Hex Bar | 10 mm – 80 mm |
| Flat Bar | 10 × 3 mm to 200 × 25 mm |
| Billet | Up to 350 mm Diameter |
| Length | 1 Meter, 3 Meter, 6 Meter & Custom Cut Length |
| Surface Finish | Mill Finish, Bright, Polished, Anodized |
| Available Shapes | Round, Square, Hexagonal, Flat |
Recent ASTM B221 Aluminium 1050 Round Bar Export Deliveries
🇺🇸
Hess Corporation
New York City, USA
UNS A91050 Round Bars, 25mm Diameter, 3m Length
Delivered in 12 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 3.0255 Bright Round Bars, 15mm Diameter
Delivered in 21 days
🇬🇧
Shell PLC
London, United Kingdom
EN AW-1050A Polished Round Bars, 20mm Diameter
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
40mm Diameter Round Bars, Aluminium 1050
Delivered in 5 days
🇯🇵
Mitsubishi Corporation
Tokyo, Japan
Cut-to-Length Round Bars, 10mm Diameter, Aluminium 1050
Delivered in 9 days
🇶🇦
QatarEnergy
Doha, Qatar
Custom Diameter Round Bars, 30–50mm, Aluminium 1050
Delivered in 18 days
stock Availability of ASTM B221 Aluminium 1050 Round Bar
| ASTM B221 Aluminium 1050 Hot Rolled Round Bar | UNS A91050 Bright Round Bar |
| WNR 3.0255 Cold Drawn Round Bar | Aluminium 1050 Polished Round Bar |
| EN AW-1050A Peeled Round Bar | ASTM B221 Aluminium 1050 Threaded Round Bar |
| Aluminium 1050 Black Round Bar | UNS A91050 Ground Round Bar |
| WNR 3.0255 Forged Round Bar | EN AW-1050A Custom Cut Round Bar |
| UNS A91050 Hot Rolled Round Bar | ASTM B221 Aluminium 1050 Bright Round Bar |
| Aluminium 1050 Cold Drawn Round Bar | WNR 3.0255 Polished Round Bar |
| EN AW-1050A Threaded Round Bar | Aluminium 1050 Peeled Round Bar |
| ASTM B221 Aluminium 1050 Ground Round Bar | UNS A91050 Black Round Bar |
| WNR 3.0255 Custom Cut Round Bar | EN AW-1050A Forged Round Bar |
ASTM B221 Aluminium 1050 Round Bar Latest Prices
Multinox INC offers WNR 3.0255 Aluminium 1050 Round Bar at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
2.71 g/cm³
Density
646 – 657°C
Melting Point
75 – 145 MPa
Tensile Strength
20 MPa Min
Yield Strength
35%
Elongation
Approx. 23 HB
Hardness
69 GPa
Modulus of Elasticity
Approximately 61% IACS
Electrical Conductivity
229 W/m·K
Thermal Conductivity
