Inconel 617 Round Bar Supplier
Gas Turbine Combustors Ask for It by Name — Multinox Inc Supplies DIN NiCr22Co12Mo9 Certified Inconel 617 Round Bar Worldwide.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
WNR 2.4663 Round Bar — Specifications
Every Inconel 617 Round Bar ships with heat-specific mill test reports — ASME SB166 documentation as standard, not an upgrade.
| Product Name | Inconel 617 Round Bar |
| Grade | Inconel 617 / UNS N06617 / WNR 2.4663 |
| Specifications | ASTM B166 / ASME SB166 |
| Standards | ASTM, ASME, DIN, EN, BS, JIS, API |
| Diameter | 14 mm to 300 mm |
| Length | 1 Meter to 6 Meters, Custom Cut Length |
| Finish | Black, Bright, Polished, Peeled, Centerless Ground |
| Forms | Round, Square, Hex, Rectangle, Billet, Forged Bar, Threaded Bar |
| Condition | Solution Annealed, Hot Rolled, Cold Drawn |
| Inspection | PMI Test, Ultrasonic Test, Mechanical Test, Third Party Inspection |
| Mill Test Certificate | EN 10204 3.1 / 3.2 |
UNS N06617 Round Bar Chemical Composition
Nickel, chromium, cobalt and molybdenum share the workload inside Inconel 617 Round Bar — oxidation, carburisation and creep each covered.
Ni
44.50 min
Nickel
Cr
20.00 – 24.00%
Chromium
Co
10.00 – 15.00%
Cobalt
Mo
8.00 – 10.00%
Molybdenum
Fe
3.00 max
Iron
Al
0.80 – 1.50%
Aluminium
C
0.05 – 0.15%
Carbon
Mn
1.00 max
Manganese
Si
1.00 max
Silicon
Ti
0.60 max
Titanium
Cu
0.50 max
Copper
B
0.006 max
Boron
S
0.015 max
Sulphur
check Equivalent Grades of ASME SB166 Round Bar
With seven recognised identities on one certificate, Inconel 617 Round Bar never delays a project at the documentation desk.
UNS
N06617
UNS
WNR
2.4663
Werkstoff No.
DIN
NiCr22Co12Mo9
German Standard
ASTM
B166
ASTM Standard
ASME
SB166
ASME Standard
Trade
Inconel 617 / Alloy 617
Trade Name
DIN NiCr22Co12Mo9 Round Bar Mechanical Properties
From combustor liners to superheater supports, Inconel 617 Round Bar keeps carrying load where most superalloys have already stepped back.
| Property | Value |
|---|---|
| Density | 8.40 g/cm³ |
| Melting Range | 1330 – 1380°C |
| Tensile Strength | 680 MPa Min |
| Yield Strength (0.2% Proof) | 300 MPa Min |
| Elongation | 35% Min |
| Hardness | 181 HB Max |
| Modulus of Elasticity | 212 GPa |
view ASME SB166 Round Bar Weight Chart
| Diameter (mm) | Weight (Kg/Mtr) |
|---|---|
| 16 | 1.69 |
| 20 | 2.64 |
| 25 | 4.12 |
| 30 | 5.93 |
| 40 | 10.55 |
| 50 | 16.49 |
| 60 | 23.74 |
| 75 | 37.10 |
| 100 | 65.96 |
| 150 | 148.42 |
| 200 | 263.84 |
check Size Range of ASTM B166 Inconel 617 Round Bar
| Product Form | Available Size |
|---|---|
| Round Bar | 14 mm – 300 mm |
| Bright Bar | 14 mm – 100 mm |
| Black Bar | 20 mm – 300 mm |
| Square Bar | 12 mm – 100 mm |
| Hex Bar | 12 mm – 75 mm |
| Flat Bar | 20 × 3 mm – 200 × 50 mm |
| Forged Bar | 100 mm – 500 mm |
| Cut Length | As Per Customer Requirement |
Recent Inconel 617 Round Bar Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
DIN NiCr22Co12Mo9 Bright Round Bars, 24mm Diameter
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
UNS N06617 Peeled & Turned Bars, 46mm
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
ASTM B166 Polished Round Bars, 30mm
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
Alloy 617 Cold Drawn Round Bars, 60mm
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
ASME SB166 Centerless Ground Bars, 85mm
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 2.4663 Hot Rolled Black Bars, 52mm
Delivered in 18 days
Availability of WNR 2.4663 Round Bar
| Inconel 617 Bright Round Bar | ASTM B166 Black Round Bar |
| UNS N06617 Polished Round Bar | ASME SB166 Peeled Round Bar |
| WNR 2.4663 Turned Round Bar | Alloy 617 Ground Round Bar |
| DIN NiCr22Co12Mo9 Cold Drawn Round Bar | Inconel 617 Hot Rolled Round Bar |
| ASTM B166 Peeled & Polished Round Bar | UNS N06617 Centerless Ground Round Bar |
| Alloy 617 Bright Bar | ASME SB166 Black Bar |
| Inconel 617 Polished Bar | WNR 2.4663 Peeled Bar |
| DIN NiCr22Co12Mo9 Turned Bar | ASTM B166 Ground Bar |
| UNS N06617 Cold Drawn Bar | Alloy 617 Hot Rolled Bar |
| ASME SB166 Peeled & Polished Bar | WNR 2.4663 Centerless Ground Bar |
WNR 2.4663 Round Bar — Latest Prices
Multinox INC offers ASTM B166 Inconel 617 Round Bars at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
