Inconel 602CA Round Bar Supplier
Hard-to-Find Alloy, Easy-to-Buy Process — Multinox Inc Exports DIN NiCr25Fe10AlY Inconel 602CA Round Bar Worldwide from Ready Stock.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
Inconel 602CA Round Bar — Specifications
Inconel 602CA Round Bar is supplied solution annealed — the condition heat-treatment equipment makers specify most.
| Product Name | Inconel 602CA Round Bar |
| Grade | Inconel 602CA / UNS N06025 / WNR 2.4633 |
| Specifications | ASTM B166 / ASME SB166 |
| Standards | ASTM, ASME, DIN, BS, EN, JIS |
| Diameter | 14 mm to 300 mm |
| Length | 1 Meter to 6 Meters, Custom Cut Length |
| Finish | Black, Bright, Polished, Peeled, Centerless Ground |
| Forms | Round, Square, Hex, Rectangle, Billet, Forged Bar |
| Condition | Hot Rolled, Cold Drawn, Annealed |
| Inspection | PMI Test, Ultrasonic Test, Third Party Inspection |
| Mill Test Certificate | EN 10204 3.1 / 3.2 |
check Chemical Composition of UNS N06025 Round Bar
The high nickel base of Inconel 602CA Round Bar takes the creep duty while chromium and aluminium handle the scaling war.
Ni
Balance
Nickel
Cr
24.00 – 26.00%
Chromium
Fe
8.00 – 11.00%
Iron
C
0.15 – 0.25%
Carbon
Al
1.80 – 2.40%
Aluminium
Ti
0.10 – 0.20%
Titanium
Y
0.05 – 0.12%
Yttrium
Zr
0.01 – 0.10%
Zirconium
Si
0.50 max
Silicon
Mn
0.15 max
Manganese
Cu
0.10 max
Copper
P
0.020 max
Phosphorus
S
0.010 max
Sulphur
view DIN NiCr25Fe10AlY Round Bar — Equivalent Grades
Inconel 602CA Round Bar clears documentation in every market — its compact but complete standards list covers all major regions.
UNS
N06025
UNS
WNR
2.4633
Werkstoff No.
DIN
NiCr25Fe10AlY
German Standard
Trade
Inconel 602CA
Trade Name
WNR 2.4633 Round Bar Mechanical Properties
Where thermal cycling destroys ordinary bars within months, Inconel 602CA Round Bar keeps its structure intact for the long haul.
| Property | Value |
|---|---|
| Density | 7.90 g/cm³ |
| Melting Range | 1320 – 1370°C |
| Tensile Strength | 724 MPa Min |
| Yield Strength (0.2% Proof) | 348 MPa Min |
| Elongation | 38% Min |
| Hardness | 220 HB Max |
| Modulus of Elasticity | 215 GPa |
Weight Chart of UNS N06025 Round Bar
| Diameter (mm) | Weight (Kg/Mtr) |
|---|---|
| 16 | 1.59 |
| 20 | 2.50 |
| 25 | 3.90 |
| 30 | 5.61 |
| 40 | 9.97 |
| 50 | 15.58 |
| 60 | 22.43 |
| 75 | 35.05 |
| 100 | 62.32 |
| 150 | 140.22 |
| 200 | 249.27 |
check Size Range of DIN NiCr25Fe10AlY Round Bar
| Product Form | Available Size |
|---|---|
| Round Bar | 14 mm – 300 mm |
| Bright Bar | 14 mm – 100 mm |
| Black Bar | 20 mm – 300 mm |
| Square Bar | 12 mm – 100 mm |
| Hex Bar | 12 mm – 75 mm |
| Flat Bar | 20 × 3 mm – 200 × 50 mm |
| Forged Bar | 100 mm – 500 mm |
| Cut Length | As Per Customer Requirement |
Recent Inconel 602CA Round Bar Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
DIN NiCr25Fe10AlY Bright Round Bars, 22mm Diameter
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
UNS N06025 Peeled & Turned Bars, 44mm
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
Inconel 602CA Polished Round Bars, 28mm
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
WNR 2.4633 Cold Drawn Round Bars, 55mm
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
80mm Centerless Ground Bars, Inconel 602CA
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 2.4633 Hot Rolled Black Bars, 50mm
Delivered in 18 days
Availability of Inconel 602CA Round Bars
| Inconel 602CA Bright Round Bar | UNS N06025 Black Round Bar |
| WNR 2.4633 Polished Round Bar | DIN NiCr25Fe10AlY Peeled Round Bar |
| Inconel 602CA Turned Round Bar | UNS N06025 Ground Round Bar |
| WNR 2.4633 Cold Drawn Round Bar | DIN NiCr25Fe10AlY Hot Rolled Round Bar |
| Inconel 602CA Peeled & Polished Round Bar | UNS N06025 Centerless Ground Round Bar |
| DIN NiCr25Fe10AlY Bright Bar | WNR 2.4633 Black Bar |
| UNS N06025 Polished Bar | Inconel 602CA Peeled Bar |
| WNR 2.4633 Turned Bar | DIN NiCr25Fe10AlY Ground Bar |
| Inconel 602CA Cold Drawn Bar | UNS N06025 Hot Rolled Bar |
| DIN NiCr25Fe10AlY Peeled & Polished Bar | WNR 2.4633 Centerless Ground Bar |
WNR 2.4633 Round Bar Latest Prices
Multinox INC offers UNS N06025 Round Bars at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
