Incoloy 825 Round Bar Supplier
Multinox Inc Holds Deep Stock of UNS N08825 Incoloy 825 Round Bar — Peeled, Ground or Black, in Diameters from 6mm to 250mm.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
JIS NCF 825 Incoloy 825 Round Bar — Specifications
Incoloy 825 Round Bar is stocked solution-annealed, certified to ASTM B425 and ASME SB425 on every order.
| Product Name | Incoloy 825 Round Bar |
| Material Grade | Incoloy Alloy 825 |
| UNS Number | N08825 |
| Werkstoff No. | 2.4858 |
| Specifications | ASTM B425 / ASME SB425 |
| Standards | ASTM, ASME, DIN, EN, JIS, BS |
| Diameter | 3 mm to 600 mm |
| Length | 0.5 Meter to 6 Meter, Custom Cut Length |
| Condition | Hot Rolled, Cold Drawn, Annealed, Forged |
| Surface Finish | Black, Bright, Polished, Pickled, Peeled |
| Forms | Round, Square, Hex, Flat, Rectangle, Billet, Forged |
| Tolerance | H8-H13, K9-K12 or as per customer requirement |
| End Finish | Plain End, Chamfered End |
| Test Certificate | EN 10204 3.1, MTC, Third Party Inspection |
| Origin | Indian, European, Japanese & USA Mill |
view AFNOR NC21FeDu Incoloy 825 Round Bar Chemical Composition
Titanium inside Incoloy 825 Round Bar stabilises the structure against intergranular attack — even after welding.
Ni
38.00 – 46.00%
Nickel
Cr
19.50 – 23.50%
Chromium
Fe
22.00 Min
Iron
Mo
2.50 – 3.50%
Molybdenum
Cu
1.50 – 3.00%
Copper
Ti
0.60 – 1.20%
Titanium
C
0.05 Max
Carbon
Mn
1.00 Max
Manganese
Si
0.50 Max
Silicon
Al
0.20 Max
Aluminium
S
0.03 Max
Sulphur
check Equivalent Grades of WNR 2.4858 Incoloy 825 Round Bar
With every major equivalent documented, Incoloy 825 Round Bar clears approvals in any market without a single query.
UNS
N08825
Unified Numbering System
Werkstoff
2.4858
Material Number
ASTM
B425
ASTM Standard
ASME
SB425
ASME Standard
EN
X5NiCrMoCuTi20-18
European Standard
JIS
NCF 825
Japanese Industrial Standard
AFNOR
NC21FeDu
French Standard
DIN
2.4858
German Standard
EN X5NiCrMoCuTi20-18 Incoloy 825 Round Bar Mechanical Properties
Incoloy 825 Round Bar resists stress corrosion cracking while holding dependable tensile values in acid-loaded environments.
| Property | Value |
|---|---|
| Density | 8.14 g/cm³ |
| Melting Range | 1370 – 1400°C |
| Tensile Strength | ≥ 585 MPa |
| Yield Strength (0.2% Offset) | ≥ 240 MPa |
| Elongation | ≥ 30% |
| Hardness | HRB 90 Max |
| Modulus of Elasticity | 196 GPa |
| Electrical Resistivity | 1.12 µΩ·m |
| Thermal Conductivity | 10.8 W/m·K |
UNS N08825 Incoloy 825 Round Bar Weight Chart
| Diameter (mm) | Weight (Kg/Meter) |
|---|---|
| 6 | 0.23 |
| 8 | 0.41 |
| 10 | 0.64 |
| 12 | 0.92 |
| 16 | 1.64 |
| 20 | 2.56 |
| 25 | 4.00 |
| 30 | 5.76 |
| 40 | 10.24 |
| 50 | 16.00 |
| 60 | 23.04 |
| 75 | 36.00 |
| 100 | 64.00 |
| 125 | 100.00 |
| 150 | 144.00 |
ASTM B425 Incoloy 825 Round Bar — Size Range
| Product Form | Available Size |
|---|---|
| Round Bar | 3 mm – 600 mm Diameter |
| Square Bar | 2 mm – 200 mm |
| Hex Bar | 3 mm – 180 mm |
| Flat Bar | 1.5 mm – 250 mm Width × 0.5 mm – 200 mm Thickness |
| Rectangular Bar | Custom Sizes Available |
| Forged Bar | Up to 600 mm Diameter |
| Length | 0.5 Meter, 3 Meter, 6 Meter & Custom Cut Length |
| Available Shapes | Round, Square, Hex, Flat, Rectangle, Billet |
Recent ASTM B425 Incoloy 825 Round Bar Export Deliveries
🇺🇸
Hess Corporation
New York City, USA
ASME SB425 Round Bars, 30mm Diameter, 3m Length
Delivered in 12 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 2.4858 Bright Round Bars, 20mm Diameter
Delivered in 21 days
🇬🇧
Shell PLC
London, United Kingdom
EN X5NiCrMoCuTi20-18 Peeled Round Bars, 25mm Diameter
Delivered in 14 days
🇯🇵
Mitsubishi Corporation
Tokyo, Japan
JIS NCF 825 Ground Round Bars, 18mm Diameter
Delivered in 10 days
🇫🇷
TotalEnergies
Paris, France
AFNOR NC21FeDu Polished Round Bars, 22mm Diameter
Delivered in 9 days
🇳🇱
AkzoNobel
Amsterdam, Netherlands
UNS N08825 Custom Diameter Round Bars, 35–80mm
Delivered in 16 days
Availability of ASTM B425 Incoloy 825 Round Bar
| ASTM B425 Incoloy 825 Hot Rolled Round Bar | UNS N08825 Bright Round Bar |
| WNR 2.4858 Cold Drawn Round Bar | Incoloy 825 Polished Round Bar |
| EN X5NiCrMoCuTi20-18 Peeled Round Bar | ASME SB425 Threaded Round Bar |
| Incoloy 825 Black Round Bar | JIS NCF 825 Ground Round Bar |
| AFNOR NC21FeDu Forged Round Bar | WNR 2.4858 Custom Cut Round Bar |
| UNS N08825 Hot Rolled Round Bar | ASTM B425 Incoloy 825 Bright Round Bar |
| Incoloy 825 Cold Drawn Round Bar | EN X5NiCrMoCuTi20-18 Polished Round Bar |
| ASME SB425 Peeled Round Bar | Incoloy 825 Threaded Round Bar |
| JIS NCF 825 Hot Rolled Round Bar | AFNOR NC21FeDu Black Round Bar |
| Incoloy 825 Forged Round Bar | UNS N08825 Custom Cut Round Bar |
Latest Prices of WNR 2.4858 Incoloy 825 Round Bar
Multinox INC offers EN X5NiCrMoCuTi20-18 Incoloy 825 Round Bars at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
