Incoloy 800HT Round Bar Supplier
Multinox Inc — Manufacturer & Exporter of WNR 1.4959 Incoloy 800HT Round Bar, Available Ex-Stock India for Fast Global Delivery.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
AFNOR NC32FeTiAl Incoloy 800HT Round — Bar Specifications
Every Incoloy 800HT Round Bar ships with mill test certificates and full heat-number traceability to UNS N08811.
| Product Name | Incoloy 800HT Round Bar |
| Material Grade | Incoloy Alloy 800HT |
| UNS Number | N08811 |
| Werkstoff No. | 1.4959 |
| Specifications | ASTM B408 / ASME SB408 |
| Standards | ASTM, ASME, DIN, EN, JIS |
| Diameter | 3 mm to 500 mm |
| Length | 1000 mm to 6000 mm, Custom Cut Length |
| Condition | Hot Rolled, Cold Drawn, Forged, Annealed |
| Surface Finish | Black, Bright, Polished, Rough Turned, Peeled |
| Forms | Round, Square, Hexagonal, Flat, Billet, Forged |
| Tolerance | h8, h9, h10, h11 or as per customer requirement |
| End Finish | Plain End, Beveled End |
| Test Certificate | EN 10204 3.1, NABL Approved Laboratory Report |
| Origin | Indian, European, Japanese & USA Mill |
WNR 1.4959 Incoloy 800HT Round Bar Chemical Composition
A higher aluminium-titanium balance separates Incoloy 800HT Round Bar from its 800H sibling — more creep strength, same corrosion resistance.
Ni
30.00 – 35.00%
Nickel
Cr
19.00 – 23.00%
Chromium
Fe
39.50 Min
Iron
C
0.06 – 0.10%
Carbon
Mn
1.50 Max
Manganese
Si
1.00 Max
Silicon
S
0.015 Max
Sulphur
Cu
0.75 Max
Copper
Al
0.15 – 0.60%
Aluminium
Ti
0.15 – 0.60%
Titanium
view Equivalent Grades of EN X8NiCrAlTi32-21 Incoloy 800HT Round Bar
Whatever designation your specification cites, Incoloy 800HT Round Bar meets it — tested, certified and fully traceable.
UNS
N08811
Unified Numbering System
Werkstoff
1.4959
Werkstoff Number
EN
X8NiCrAlTi32-21
European Standard
AFNOR
NC32FeTiAl
French Standard
JIS
NCF 800HT
Japanese Industrial Standard
ISO
NW 8811
International Standard
check Mechanical Properties of UNS N08811 Incoloy 800HT Round Bar
Aluminium and titanium give Incoloy 800HT Round Bar its age-hardening edge — strength that grows with controlled heat treatment.
| Property | Value |
|---|---|
| Density | 7.94 g/cm³ |
| Melting Range | 1357 – 1385°C |
| Tensile Strength | ≥ 450 MPa |
| Yield Strength (0.2% Offset) | ≥ 170 MPa |
| Elongation | ≥ 30% |
| Hardness | HRB 70–90 (Approx.) |
| Modulus of Elasticity | 196 GPa |
| Electrical Resistivity | 0.989 µΩ·m |
| Thermal Conductivity | 11.5 W/m·K (Approx.) |
AFNOR NC32FeTiAl Incoloy 800HT Round Bar Weight Chart
| Diameter (mm) | Weight (Kg/Meter) |
|---|---|
| 6 | 0.22 |
| 8 | 0.40 |
| 10 | 0.62 |
| 12 | 0.89 |
| 16 | 1.59 |
| 20 | 2.49 |
| 25 | 3.89 |
| 30 | 5.60 |
| 40 | 9.95 |
| 50 | 15.55 |
| 60 | 22.40 |
| 65 | 26.30 |
| 75 | 35.00 |
| 80 | 39.80 |
| 90 | 50.40 |
| 100 | 62.35 |
| 125 | 97.40 |
| 150 | 140.30 |
| 200 | 249.40 |
EN X8NiCrAlTi32-21 Incoloy 800HT Round Bar — Size Range
| Product Form | Available Size |
|---|---|
| Round Bar | 3 mm – 500 mm Diameter |
| Square Bar | 10 mm – 100 mm |
| Hex Bar | 10 mm – 100 mm |
| Flat Bar | 10 × 3 mm to 200 × 50 mm |
| Forged Bar | Up to 500 mm Diameter |
| Length | 1 Meter, 3 Meter, 6 Meter & Custom Cut Length |
| Finish | Black, Bright, Polished, Peeled, Rough Turned |
| Available Shape | Round, Square, Hexagonal, Flat |
Recent ASTM B408 Incoloy 800HT Round Bar Export Deliveries
🇺🇸
Hess Corporation
New York City, USA
UNS N08811 Round Bars, 25mm Diameter, 3m Length
Delivered in 12 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 1.4959 Bright Round Bars, 18mm Diameter
Delivered in 21 days
🇬🇧
Shell PLC
London, United Kingdom
EN X8NiCrAlTi32-21 Peeled Round Bars, 22mm Diameter
Delivered in 14 days
🇫🇷
TotalEnergies
Paris, France
AFNOR NC32FeTiAl Polished Round Bars, 20mm Diameter
Delivered in 9 days
🇯🇵
Mitsubishi Corporation
Tokyo, Japan
JIS NCF 800HT Ground Round Bars, 16mm Diameter
Delivered in 10 days
🇮🇹
Danieli S.p.A.
Buttrio, Italy
ISO NW 8811 Furnace-Grade Round Bars, 30mm Diameter
Delivered in 16 days
Availability of JIS NCF 800HT Incoloy 800HT Round Bars
| ASTM B408 Incoloy 800HT Hot Rolled Round Bar | UNS N08811 Bright Round Bar |
| WNR 1.4959 Cold Drawn Round Bar | Incoloy 800HT Polished Round Bar |
| EN X8NiCrAlTi32-21 Peeled Round Bar | ASME SB408 Threaded Round Bar |
| Incoloy 800HT Black Round Bar | JIS NCF 800HT Ground Round Bar |
| AFNOR NC32FeTiAl Forged Round Bar | ISO NW 8811 Custom Cut Round Bar |
| UNS N08811 Hot Rolled Round Bar | ASTM B408 Incoloy 800HT Bright Round Bar |
| Incoloy 800HT Cold Drawn Round Bar | WNR 1.4959 Polished Round Bar |
| ISO NW 8811 Peeled Round Bar | Incoloy 800HT Threaded Round Bar |
| ASTM B408 Incoloy 800HT Ground Round Bar | AFNOR NC32FeTiAl Black Round Bar |
| Incoloy 800HT Forged Round Bar | JIS NCF 800HT Custom Cut Round Bar |
WNR 1.4959 Incoloy 800HT Round Bar Latest Prices
Multinox INC offers UNS N08811 Incoloy 800HT Round Bar s at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
