AMS 5659 15-5PH Stainless Steel Round Bar Supplier
Choose Multinox Inc for WNR 1.4545 15-5PH Stainless Steel Round Bar — Where Every Bar is Tested Before It Ships, Not After.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
Specifications of AMS 5659 15-5PH Stainless Steel Round Bar
15-5PH Stainless Steel Round Bar is supplied solution-treated or in the age-hardened condition — exactly as your drawing demands.
| Product | AMS 5659 15-5PH Stainless Steel Round Bar |
| Specifications | AMS 5659, ASTM A564 |
| Dimensions / Standards | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| UNS S15500 Round Bars | Diameter: 3 mm – 800 mm |
| DIN 1.4545 Round Bars | Diameter: 3 mm – 100 mm |
| 15-5PH Hex Bars | 2 mm – 100 mm A/F |
| UNS S15500 Square Bars | 4 mm – 100 mm |
| 1.4545 Flat Bars | Thickness: 2 – 100 mm, Width: 10 – 500 mm |
| Finish | Cold Drawn, Bright, Centreless Ground, Hot Rolled, Rough Turned, Black, Polished |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Form | Round, Square, Hex, Flat, Rectangle, Hollow, Billet, Threaded, Forging, Precision Ground Bar, Channel, Triangle |
View UNS S15500 15-5PH Stainless Steel Round Bar Chemical Composition
The copper addition is the secret behind 15-5PH Stainless Steel Round Bar's remarkable strength gain during heat treatment.
C
0.07 max
Carbon
Mn
1.00 max
Manganese
Si
1.00 max
Silicon
P
0.040 max
Phosphorus
S
0.030 max
Sulphur
Cr
14.00 – 15.50%
Chromium
Ni
3.50 – 5.50%
Nickel
Cb+Ta
0.15 – 0.45%
Columbium + Tantalum
Fe
Balance
Iron
Equivalent Grades — WNR 1.4545 15-5PH Stainless Steel Round Bar
Known as UNS S15500 in America and WNR 1.4545 in Europe — 15-5PH Stainless Steel Round Bar is recognised by every major standard.
UNS
S15500
UNS
WNR
1.4545
Werkstoff
15-5PH Stainless Steel Round Bar Mechanical Properties
From landing gear to high-pressure valve stems, 15-5PH Stainless Steel Round Bar carries extreme loads without a hint of brittleness.
| Condition | Ultimate Tensile Strength (ksi) | Yield Strength (ksi) | Elongation (%) | Reduction of Area (%) | Hardness |
|---|---|---|---|---|---|
| Condition A | — | — | — | — | 363 HB Max |
| H900 | 190 | 170 | 10 | 35 | 388–444 HB |
| H925 | 170 | 155 | 10 | 38 | 375–429 HB |
| H1025 | 155 | 145 | 12 | 45 | 331–401 HB |
| H1075 | 145 | 125 | 13 | 45 | 311–375 HB |
| H1100 | 140 | 115 | 14 | 45 | 302–363 HB |
| H1150 | 135 | 105 | 16 | 50 | 277–352 HB |
UNS S15500 15-5PH Stainless Steel Round Bar — Weight Chart
| Diameter (mm) | Weight (kg/m) |
|---|---|
| 6 | 0.22 |
| 8 | 0.39 |
| 10 | 0.62 |
| 12 | 0.89 |
| 16 | 1.58 |
| 20 | 2.47 |
| 25 | 3.85 |
| 30 | 5.55 |
| 40 | 9.87 |
| 50 | 15.42 |
| 60 | 22.20 |
| 75 | 34.68 |
| 100 | 61.65 |
Weight Formula: Weight (kg/m) = (D² × 0.006165), where D is the bar diameter in millimeters.
Size Range of WNR 1.4545 15-5PH Stainless Steel Round Bar
| Product Form | Available Size |
|---|---|
| Round Bar | 3 – 800 mm Diameter |
| Flat Bar | Thickness: 2 –100 mm, Width: 10 –500 mm |
| Angle Bar | 3×20×20 mm – 12×100×100 mm |
| Channel Bar | 80×40 mm to 150×75 mm |
| Rectangular Bar | 33×30 mm to 295×1066 mm |
| Hollow Bar | 32 mm OD ×16 mm ID to 250 mm OD ×200 mm ID |
| Billet | 1/2" to 495 mm Diameter |
| Length | 1–6 Meters, Custom Cut Lengths |
Recent AMS 5659 15-5PH Stainless Steel Round Bar Export Deliveries
🇺🇸
Hess Corporation
New York City, USA
UNS S15500 Round Bars, 30mm Diameter, 3m Length
Delivered in 12 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 1.4545 Bright Round Bars, 20mm Diameter
Delivered in 21 days
🇫🇷
Safran S.A.
Paris, France
AMS 5659 Age-Hardened Round Bars, 45mm Diameter
Delivered in 9 days
🇮🇱
Israel Aerospace Industries
Lod, Israel
Ground Round Bars, 25mm Diameter, 15-5PH
Delivered in 13 days
🇯🇵
Mitsubishi Corporation
Tokyo, Japan
Cut-to-Length Round Bars, 15mm Diameter, 15-5PH
Delivered in 10 days
🇮🇳
Hindustan Aeronautics Limited
Bengaluru, India
Custom Diameter Round Bars, 35–80mm, 15-5PH
Delivered in 6 days
Availability of 15-5PH Stainless Steel Round Bar
| AMS 5659 15-5PH Hot Rolled Round Bar | UNS S15500 Bright Round Bar |
| WNR 1.4545 Cold Drawn Round Bar | 15-5PH Polished Round Bar |
| 15-5PH Peeled Round Bar | AMS 5659 15-5PH Threaded Round Bar |
| 15-5PH Black Round Bar | UNS S15500 Ground Round Bar |
| WNR 1.4545 Forged Round Bar | UNS S15500 Custom Cut Round Bar |
| UNS S15500 Hot Rolled Round Bar | AMS 5659 15-5PH Bright Round Bar |
| 15-5PH Cold Drawn Round Bar | WNR 1.4545 Polished Round Bar |
| AMS 5659 15-5PH Peeled Round Bar | 15-5PH Threaded Round Bar |
| WNR 1.4545 Ground Round Bar | 15-5PH Black Round Bar |
| UNS S15500 Forged Round Bar | WNR 1.4545 Custom Cut Round Bar |
WNR 1.4545 15-5PH Stainless Steel Round Bar — Latest Prices
Multinox INC offers Stainless Steel Round Bars at one of the most competitive prices in India. Request the latest Stainless Steel Round Bars Pricelist using the contact form here.
