AL-6XN Round Bar Supplier
Fully Certified EN X1NiCrMoCuN25-20-7 AL-6XN Round Bar — Multinox Inc Ships Test-Reported Bars to Fabricators in 50+ Countries.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
AL-6XN Round Bar Specifications
Multinox Inc supplies AL-6XN Round Bar in bright, black, turned and ground finishes — every bar inspected before dispatch.
| Product | AL-6XN Stainless Steel Round Bar |
| Specifications | ASTM B691 / ASME SB691 |
| Dimensions / Standards | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| UNS N08367 Round Bars | Diameter: 3 mm – 800 mm |
| 1.4529 Hex Bars | 2 mm – 100 mm A/F |
| X1NiCrMoCuN25-20-7 Square Bars | 4 mm – 100 mm |
| UNS N08367 Flat Bars | Thickness: 2 – 100 mm, Width: 10 – 500 mm |
| Finish | Cold Drawn (Bright), Centreless Ground, Hot Rolled, Smooth Turned, Peeled, Rough Turned, Bright, Polished, Black |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Form | Round, Rod, Flat, Square, Hex, Rectangle, Triangle, Hollow, Threaded, Billet, Ingot, Forging, Precision Ground Bar |
UNS N08367 Round Bar — Chemical Composition
The nitrogen-strengthened, molybdenum-rich chemistry of AL-6XN Round Bar was engineered specifically to beat chloride attack.
C
0.03 max
Carbon
Mn
2.00 max
Manganese
Si
1.00 max
Silicon
P
0.04 max
Phosphorus
S
0.03 max
Sulphur
Cr
20.0 – 22.0%
Chromium
Ni
23.5 – 25.5%
Nickel
Mo
6.0 – 7.0%
Molybdenum
Equivalent Grades of WNR 1.4529 Round Bar
One bar, three passports — AL-6XN Round Bar is documented as UNS N08367, WNR 1.4529 and EN X1NiCrMoCuN25-20-7.
UNS
N08367
UNS
WNR
1.4529
Werkstoff
EN
X1NiCrMoCuN25-20-7
European Standard
BS
X1NiCrMoCuN25-20-7
British Standard
AFNOR
Z2NCDU25-20-06Az
French Standard
EN X1NiCrMoCuN25-20-7 Round Bar Mechanical Properties
AL-6XN Round Bar pairs impressive tensile strength with excellent toughness — performance that survives both pressure and punishment.
| Property | Value |
|---|---|
| Density | — |
| Melting Point | — |
| Tensile Strength | 690 MPa Min |
| Yield Strength (0.2% Offset) | 310 MPa Min |
| Elongation | 30% |
Weight Chart for UNS N08367 Round Bar
| Diameter (mm) | Weight (kg/m) |
|---|---|
| 6 | 0.22 |
| 8 | 0.39 |
| 10 | 0.62 |
| 12 | 0.89 |
| 16 | 1.58 |
| 20 | 2.47 |
| 25 | 3.85 |
| 30 | 5.55 |
| 40 | 9.87 |
| 50 | 15.42 |
| 60 | 22.20 |
| 75 | 34.68 |
| 100 | 61.65 |
Weight Formula: Weight (kg/m) = (D² × 0.006165), where D is the bar diameter in millimeters.
Size Range of EN X1NiCrMoCuN25-20-7 Round Bar
| Product Form | Available Size |
|---|---|
| Round Bar | 3 – 800 mm Diameter |
| Hex Bar | 2 – 100 mm A/F |
| Square Bar | 4 – 100 mm |
| Flat Bar | Thickness: 2 – 100 mm, Width: 10 – 500 mm |
| Angle Bar | 3 × 20 × 20 mm to 12 × 100 × 100 mm |
| Channel Bar | 80 × 40 mm to 150 × 75 mm |
| Rectangular Bar | 33 × 30 mm to 295 × 1066 mm |
| Hollow Bar | 32 mm OD × 16 mm ID to 250 mm OD × 200 mm ID |
| Billet | 1/2" to 495 mm Diameter |
| Length | 1–6 Meters, Custom Cut Lengths |
Recent AL-6XN Round Bar Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
30mm Diameter Bright Round Bars, AL-6XN
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
UNS N08367 Peeled & Turned Bars, 60mm
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
EN X1NiCrMoCuN25-20-7 Polished Round Bars, 25mm
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
Hot Rolled Round Bars, 80mm Diameter
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
120mm Centerless Ground Bars, AL-6XN
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 1.4529 Cold Drawn Black Bars, 40mm
Delivered in 18 days
Available stock of WNR 1.4529 Round Bar
| AL-6XN Bright Round Bar | UNS N08367 Black Round Bar |
| WNR 1.4529 Polished Round Bar | EN X1NiCrMoCuN25-20-7 Peeled Round Bar |
| AL-6XN Turned Round Bar | UNS N08367 Ground Round Bar |
| WNR 1.4529 Hot Rolled Round Bar | EN X1NiCrMoCuN25-20-7 Cold Drawn Round Bar |
| AL-6XN Peeled & Polished Round Bar | UNS N08367 Centerless Ground Round Bar |
| UNS N08367 AL-6XN Bright Bar | WNR 1.4529 AL-6XN Black Bar |
| EN X1NiCrMoCuN25-20-7 AL-6XN Polished Bar | AL-6XN UNS N08367 Peeled Bar |
| WNR 1.4529 AL-6XN Turned Bar | AL-6XN EN X1NiCrMoCuN25-20-7 Ground Bar |
| UNS N08367 AL-6XN Hot Rolled Bar | AL-6XN WNR 1.4529 Cold Drawn Bar |
| EN X1NiCrMoCuN25-20-7 AL-6XN Peeled & Polished Bar | AL-6XN UNS N08367 Centerless Ground Bar |
EN X1NiCrMoCuN25-20-7 Round Bar Latest Prices
Multinox INC offers UNS N08367 Round Bar at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
