Aluminium 5754 Round Bar Supplier
Multinox Inc Keeps Aluminium 5754 Round Bar (EN AW-5754 / DIN 3.3535) Moving — Same-Week Dispatch to Shipyards & Plants Worldwide.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
EN AW-5754 Round Bar Dimensions
Aluminium 5754 Round Bar comes in every commercial diameter with cut-to-length service — order exactly what your job needs.
| Specifications | ASTM B221 / ASTM B211 / ASME SB221 |
| Standards | ASTM, ASME, EN, DIN, JIS, ISO |
| Diameter | 5 mm to 350 mm |
| Length | 1000 mm to 6000 mm, Custom Cut Length Available |
| Manufacturing Process | Extruded, Cold Drawn, Hot Rolled |
| Temper | O, H, T4, T5, T6, T651 (Depending on Alloy) |
| Surface Finish | Mill Finish, Bright Finish, Polished, Anodized |
| Forms | Round, Square, Hexagonal, Flat, Billet |
| Tolerance | As per ASTM B221 or Customer Specification |
| Available Lengths | 1 Meter, 3 Meter, 6 Meter & Cut-to-Length |
| Origin | Indian, European, Japanese & USA Mills |
| Marking | Grade, Size, Heat Number, Manufacturer's Identification |
| Packaging | Wooden Boxes, HDPE Wrapped Bundles, Plastic End Caps, Export Worthy Packing |
| Test Certificates | EN 10204 3.1, Mill Test Certificate (MTC), Third Party Inspection, PMI Test (On Request) |
| Applications | Aerospace, Marine, Automotive, Chemical Processing, Food Processing, Electrical, Construction, Oil & Gas, Engineering Industries |
DIN 3.3535 Round Bar — Chemical Composition
Three percent magnesium is the magic number in Aluminium 5754 Round Bar — enough for strength, still a dream to weld.
Al
Balance
Aluminium
Mg
2.60 – 3.60%
Magnesium
Mn
0.50 Max
Manganese
Si
0.40 Max
Silicon
Fe
0.40 Max
Iron
Cr
0.30 Max
Chromium
Cu
0.10 Max
Copper
Zn
0.20 Max
Zinc
Ti
0.15 Max
Titanium
Oth.
0.05 Max
Others (Each)
ΣOth.
0.15 Max
Others (Total)
Equivalent Grades of Aluminium 5754 Round Bar
Specify AA 5754, UNS A95754, EN AW-5754 or DIN 3.3535 — every name leads to the same dependable Aluminium 5754 Round Bar.
AA
5754
Aluminum Association
UNS
A95754
Unified Numbering System
EN
EN AW-5754
European Standard
DIN
3.3535
German Standard
ISO
AlMg3
International Standard
JIS
A5754
Japanese Industrial Standard
AA 5754 Round Bar Mechanical Properties
Fatigue resistance is where Aluminium 5754 Round Bar quietly outperforms — vibration-heavy decks and frames depend on it.
| Property | Value |
|---|---|
| Density | 2.66 g/cm³ |
| Melting Point | 600 – 645°C |
| Tensile Strength | 190 – 240 MPa |
| Yield Strength | 80 MPa Min |
| Elongation | 18% |
| Hardness | Approx. 63 HB |
| Modulus of Elasticity | 68 GPa |
| Electrical Conductivity | 33% IACS |
| Thermal Conductivity | 147 W/m·K |
Aluminium 5754 Round Bar Weight Chart
| Diameter (mm) | Weight (Kg/Meter) |
|---|---|
| 6 | 0.08 |
| 8 | 0.13 |
| 10 | 0.21 |
| 12 | 0.30 |
| 16 | 0.53 |
| 20 | 0.84 |
| 25 | 1.31 |
| 30 | 1.88 |
| 40 | 3.34 |
| 50 | 5.22 |
| 60 | 7.52 |
| 75 | 11.74 |
| 100 | 20.88 |
Check UNS A95754 Round Bar Size Range
| Product Form | Available Size |
|---|---|
| Round Bar | 5 mm – 350 mm Diameter |
| Square Bar | 10 mm – 100 mm |
| Hex Bar | 10 mm – 80 mm |
| Flat Bar | 10 × 3 mm to 200 × 25 mm |
| Billet | Up to 350 mm Diameter |
| Length | 1 Meter, 3 Meter, 6 Meter & Custom Cut Length |
| Surface Finish | Mill Finish, Bright, Polished, Anodized |
| Available Shapes | Round, Square, Hexagonal, Flat |
Recent Aluminium 5754 Round Bar Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
20mm Diameter Bright Round Bars, Aluminium 5754
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
UNS A95754 Peeled & Turned Bars, 45mm
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
EN AW-5754 Polished Round Bars, 25mm
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
Cold Drawn Round Bars, 65mm Diameter
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
90mm Ground Bars, Aluminium 5754
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
DIN 3.3535 Hot Rolled Black Bars, 55mm
Delivered in 18 days
Availability of UNS A95754 Round Bar
| Aluminium 5754 Bright Round Bar | AA 5754 Black Round Bar |
| UNS A95754 Polished Round Bar | EN AW-5754 Peeled Round Bar |
| DIN 3.3535 Turned Round Bar | Aluminium 5754 Ground Round Bar |
| AA 5754 Cold Drawn Round Bar | UNS A95754 Hot Rolled Round Bar |
| EN AW-5754 Peeled & Polished Round Bar | DIN 3.3535 Centerless Ground Round Bar |
| AA 5754 Bright Bar | UNS A95754 Black Bar |
| EN AW-5754 Polished Bar | DIN 3.3535 Peeled Bar |
| Aluminium 5754 Turned Bar | AA 5754 Ground Bar |
| UNS A95754 Cold Drawn Bar | EN AW-5754 Hot Rolled Bar |
| DIN 3.3535 Peeled & Polished Bar | Aluminium 5754 Centerless Ground Bar |
Latest Prices of Aluminium 5754 Round Bar
Multinox INC offers UNS A95754 Round Bars at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
