Aluminium 1060 Round Bar Supplier
Multinox Inc — Pure Aluminium Power — UNS A91060 Aluminium 1060 Round Bars Stocked & Exported Worldwide.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
UNS A91060 Round Bar Specifications
Electrical busbar projects or chemical equipment — Aluminium 1060 Round Bars arrive mill-certified with full traceability.
| Specifications | ASTM B221 / ASTM B211 / ASME SB221 |
| Standards | ASTM, ASME, EN, DIN, JIS, ISO |
| Diameter | 5 mm to 350 mm |
| Length | 1000 mm to 6000 mm, Custom Cut Length Available |
| Manufacturing Process | Extruded, Cold Drawn, Hot Rolled |
| Temper | O, H, T4, T5, T6, T651 (Depending on Alloy) |
| Surface Finish | Mill Finish, Bright Finish, Polished, Anodized |
| Forms | Round, Square, Hexagonal, Flat, Billet |
| Tolerance | As per ASTM B221 or Customer Specification |
| Available Lengths | 1 Meter, 3 Meter, 6 Meter & Cut-to-Length |
| Origin | Indian, European, Japanese & USA Mills |
| Marking | Grade, Size, Heat Number, Manufacturer's Identification |
| Packaging | Wooden Boxes, HDPE Wrapped Bundles, Plastic End Caps, Export Worthy Packing |
| Test Certificates | EN 10204 3.1, Mill Test Certificate (MTC), Third Party Inspection, PMI Test (On Request) |
| Applications | Aerospace, Marine, Automotive, Chemical Processing, Food Processing, Electrical, Construction, Oil & Gas, Engineering Industries |
View Chemical Composition of EN AW-1060A Round Bar
The minimal iron and silicon traces inside Aluminium 1060 Round Bars are tightly controlled — purity is the whole point.
Al
99.60 Min
Aluminium
Si
0.25 Max
Silicon
Fe
0.35 Max
Iron
Cu
0.05 Max
Copper
Mn
0.03 Max
Manganese
Mg
0.03 Max
Magnesium
Zn
0.05 Max
Zinc
Ti
0.03 Max
Titanium
Oth.
0.03 Max
Others (Each)
ΣOth.
0.20 Max
Others (Total)
WNR 3.0255 Round Bar Equivalent Grades
International buyers trust Aluminium 1060 Round Bars because every standard system recognises the same certified quality.
AA
1060
Aluminum Association
UNS
A91060
Unified Numbering System
EN
EN AW-1060A
European Standard
DIN
3.0255
German Standard
ISO
Al99.6
International Standard
JIS
A1060
Japanese Industrial Standard
Mechanical Properties — ISO Al99.6 Round Bar
Aluminium 1060 Round Bars bend, upset and swage without cracking — the easiest machining aluminium you'll ever handle.
| Property | Value |
|---|---|
| Density | 2.70 g/cm³ |
| Melting Point | 646 – 657°C |
| Tensile Strength | 95 – 125 MPa |
| Yield Strength | 35 MPa Min |
| Elongation | 30% |
| Hardness | Approx. 30 HB |
| Modulus of Elasticity | 69 GPa |
| Electrical Conductivity | Approximately 59% IACS |
| Thermal Conductivity | 230 W/m·K |
UNS A91060 Round Bar — Weight Chart
| Diameter (mm) | Weight (Kg/Meter) |
|---|---|
| 6 | 0.08 |
| 8 | 0.13 |
| 10 | 0.21 |
| 12 | 0.30 |
| 16 | 0.53 |
| 20 | 0.84 |
| 25 | 1.31 |
| 30 | 1.88 |
| 40 | 3.34 |
| 50 | 5.22 |
| 60 | 7.52 |
| 75 | 11.74 |
| 100 | 20.88 |
UNS A91060 Round Bar Size Range
| Product Form | Available Size |
|---|---|
| Round Bar | 5 mm – 350 mm Diameter |
| Square Bar | 10 mm – 100 mm |
| Hex Bar | 10 mm – 80 mm |
| Flat Bar | 10 × 3 mm to 200 × 25 mm |
| Billet | Up to 350 mm Diameter |
| Length | 1 Meter, 3 Meter, 6 Meter & Custom Cut Length |
| Surface Finish | Mill Finish, Bright, Polished, Anodized |
| Available Shapes | Round, Square, Hexagonal, Flat |
Recent UNS A91060 Aluminium 1060 Round Bar Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
20mm Diameter Bright Bars, Aluminium 1060
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
UNS A91060 Extruded Bars, 40mm Diameter
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
EN AW-1060A Drawn Bars, 16mm Diameter
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
H14 Temper Bars, 25mm Diameter, Aluminium 1060
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
80–150mm Diameter Hot Rolled Bars, Aluminium 1060
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
WNR 3.0255 Turned Bars, 30–60mm Diameter
Delivered in 18 days
Availability of ISO Al99.6 Round Bar
| Aluminium 1060 Bright Round Bar | UNS A91060 Black Round Bar |
| EN AW-1060A Polished Round Bar | WNR 3.0255 Peeled Round Bar |
| ISO Al99.6 Turned Round Bar | Aluminium 1060 Ground Round Bar |
| UNS A91060 Hot Rolled Round Bar | EN AW-1060A Cold Drawn Round Bar |
| WNR 3.0255 Extruded Round Bar | ISO Al99.6 Bright Round Bar |
| Aluminium 1060 Black Round Bar | UNS A91060 Polished Round Bar |
| EN AW-1060A Peeled Round Bar | WNR 3.0255 Turned Round Bar |
| ISO Al99.6 Ground Round Bar | Aluminium 1060 Hot Rolled Round Bar |
| UNS A91060 Cold Drawn Round Bar | EN AW-1060A Extruded Round Bar |
| WNR 3.0255 Bright Round Bar | ISO Al99.6 Polished Round Bar |
Latest Prices of UNS A91060 Round Bar
Multinox INC offers ISO Al99.6 Round Bar at one of the most competitive prices in India. Request the latest Pricelist using the contact form here.
