Stainless Steel 316Ti Pipe Supplier
Multinox INC is a leading manufacturer and supplier of 316Ti SS Pipes & Tubes. The increased chromium and molybdenum in Stainless Steel 316ti Pipes and Stainless Steel 316ti Tubes content provides a better and increased resistance to corrosion which facilitates usage in food preparation equipment, especially in chloride environments, chemical processing equipments and Pharmaceutical and textile industries among others.
We provide 316ti Steel Seamless Pipes and 316ti Stainless Steel Tubing which comply with international standards. Our specialty includes Stainless Steel 316ti EFW Pipes which are cold-rolled precision strips used for technical applications. We also manufacture SS 316ti Round Pipes to tightly defined specifications. Our Stainless Steel 316ti Tubes are better alternatives to carbon steel products, because of its increased resistance to corrosion. The Stainless Steel 316ti Round Pipes we manufacture are made to tightly defined strengths, surface tension and texture.
We have record of supplying high quality 316ti Stainless Steel Welded Tubes which has a lower carbon limit and better mechanical properties. Stainless Steel 316ti ERW Tubes are being used for countless application since the invention of stainless steel. Our Stainless Steel 316ti Electopolished Tubes are gaining recognition in the industry for its quality and better properties.
Take a look at our widest selection of Stainless Steel 316ti Pipes & Tubes, and Contact us to let us know your specific requirements, so that our dedicated team and support staff can help you with your needs.
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
Specifications
| Standard | ASTM A312 / ASME SA312 |
| Type | Seamless, Welded (ERW, EFW, SAW), Fabricated |
| Seamless Pipe Size | 1/8″ – 12″ NPS, Wall Thickness: 0.6 – 12.7 mm |
| Welded Pipe Size | OD: 6.35 – 114.3 mm, Length: Up to 26 m |
| Heavy Wall Pipe Size | OD: 10 – 600 mm, Wall Thickness: 2.5 – 100 mm |
| Schedule | 5S, 10S, 40S, 80S, 100, 120, 140, 160, XXH |
| Form | Round, Square, Rectangular, Oval |
| Finish | Bright, Annealed, Mirror, Polished |
| End | Plain End, Beveled End |
| Testing | UT, RT, MT, PT, ET, PMI, Visual Inspection |
| Certifications | ISO 9001, ISO 14001, OHSAS 18001, PED, NORSOK |
| HSN Code | 73044900 |
Chemical Composition
Ni
10.0 – 14.0
Nickel
C
0.08 Max
Carbon
Mn
2.0 Max
Manganese
P
0.045 Max
Phosphorus
S
0.03 Max
Sulfur
Si
0.75 Max
Silicon
Cr
16.0 – 18.0
Chromium
Mo
2.0 – 3.0
Molybdenum
Equivalent Grades
UNS
S31635
UNS Number
BS
320S31
Old British Standard
EN
X6CrNiMoTi17-12-2
European Standard
GOST
08Ch17N13M2T
Russian Standard
W.NR.
1.4571
Werkstoff Number
JIS
SUS 316Ti
Japanese Standard
Mechanical Properties
316°C
Test Temperature
159 MPa
Yield Strength
443 MPa
Tensile Strength
26%
Elongation
Weight Chart
| NPS (in) | Wall Thickness (in) | Wall Thickness (mm) | OD (in) | OD (mm) | Schedule | Weight (kg/m) |
|---|---|---|---|---|---|---|
| 1/2" | 0.109 | 2.769 | 0.840 | 21 | 40 | 1.268 |
| 1/2" | 0.147 | 3.734 | 0.840 | 21 | 80 | 1.621 |
| 3/4" | 0.113 | 2.870 | 1.050 | 27 | 40 | 1.684 |
| 3/4" | 0.154 | 3.912 | 1.050 | 27 | 80 | 2.195 |
| 1" | 0.133 | 3.378 | 1.315 | 33 | 40 (STD) | 2.501 |
| 1" | 0.179 | 4.547 | 1.315 | 33 | 80 | 3.325 |
| 1 1/4" | 0.140 | 3.556 | 1.660 | 42 | 40 | 3.385 |
| 1 1/4" | 0.191 | 4.851 | 1.660 | 42 | 80 | 4.464 |
| 1 1/2" | 0.145 | 3.683 | 1.900 | 48 | 40 | 4.048 |
| 1 1/2" | 0.200 | 5.080 | 1.900 | 48 | 80 | 5.409 |
| 2" | 0.154 | 3.912 | 2.375 | 60 | 40 | 5.441 |
| 2" | 0.218 | 5.537 | 2.375 | 60 | 80 | 7.480 |
| 2 1/2" | 0.203 | 5.516 | 2.875 | 73 | 40 | 8.629 |
| 2 1/2" | 0.276 | 7.010 | 2.875 | 73 | 80 | 11.411 |
| 3" | 0.216 | 5.486 | 3.500 | 89 | 40 | 11.284 |
| 3" | 0.300 | 7.620 | 3.500 | 89 | 80 | 15.272 |
| 4" | 0.237 | 6.020 | 4.500 | 114 | STD | 16.073 |
| 4" | 0.337 | 8.560 | 4.500 | 114 | XS | 22.318 |
| 6" | 0.188 | 4.775 | 6.625 | 168 | STD | 19.252 |
| 6" | 0.203 | 5.516 | 6.625 | 168 | XS | 20.739 |
| 6" | 0.280 | 7.112 | 6.625 | 168 | 40 | 28.263 |
| 6" | 0.312 | 7.925 | 6.625 | 168 | 80 | 31.334 |
Recent Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
304 SS Round Bars, 50mm OD, ASTM A276
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
SS 304 Hex Bars, 40mm A/F, Cold Drawn
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
304 SS Flat Bars, 100×20mm, Bright Finish
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
304 SS Square Bars, 40mm, Forged Grade
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
SS 304 Hollow Bars, 80mm OD × 20mm wall
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
304 SS Round Bars 25–100mm, EN 10204 3.2
Delivered in 18 days
Availability of Stainless Steel Pipes
| Stainless Steel 304 Pipe | Stainless Steel 304L Pipe |
| Stainless Steel 316 Pipe | Stainless Steel 316L Pipe |
| Stainless Steel 316Ti Pipe | Stainless Steel 310 Pipe |
| Stainless Steel 317L Pipe | Stainless Steel 321 Pipe |
| Stainless Steel 347 Pipe | Stainless Steel 347H Pipe |
| Stainless Steel 410 Pipe | Stainless Steel 416 Pipe |
| Stainless Steel 420 Pipe | Stainless Steel 430 Pipe |
| Stainless Steel 440 Pipe | Stainless Steel 440C Pipe |
| Stainless Steel 446 Pipe | Stainless Steel S44600 Pipe |
| Stainless Steel EN 1.4749 Pipe | Stainless Steel 17-4PH Pipe |
| Stainless Steel 15-5PH Pipe |
Latest Prices of Pipes
Multinox INC offers Pipes at one of the most competitive prices in India. Request the latest Pipes Pricelist using the contact form here.
