Inconel 617 Pipe Supplier
Available Forms & Types
Most Common
Round Bars
Cold drawn, centreless ground & polished. Used in shafts, fasteners, machined components.
- OD: 4mm to 500mm
- Bright / Polish / Black finish
- Length: 1–6 metres
Precision
Hex Bars
Across-flat 18mm–57mm. Ideal for bolt, nut & valve body machining applications.
- 18mm – 57mm A/F
- Cold drawn condition
- Non-magnetic grade
Structural
Square Bars
Used in structural fabrication, tooling and engineering. Custom sizes available.
- 18mm – 47mm
- Bright / Rough Turned
- Custom sizes on request
Wide Range
Flat Bars
Width ½" to 10", thickness 2mm to 150mm. Sheared & edged or hot-rolled condition.
- Width: ½" to 10"
- Thickness: 2–150mm
- Custom width available
Hollow
Hollow Bars
Seamless hollow bar for bushings, sleeves & valve bodies. Saves machining time.
- OD: 4mm to 100mm
- Various wall thickness
- Centreless ground
High Strength
Forged Bars
Hot forged for superior grain structure. Heavy-duty industrial and aerospace use.
- 15mm to 300mm
- Ultrasonic tested
- Rough turned finish
Specifications
| Specifications | ASTM / ASME (As Per Grade) |
| Dimensions | ASTM, ASME, ANSI B36.10M, ANSI B36.19M & API |
| Seamless Pipe Size | 4 mm to 219 mm (1/8" NB to 24" NB) |
| Welded Pipe Size | 5 mm to 1219.2 mm (1/8" NB to 48" NB) |
| EFW Pipe Size | 6" NB to 100" NB |
| Wall Thickness | 0.5 mm to 20 mm |
| Schedule | SCH 5, SCH 10, SCH 20, SCH 30, SCH 40, STD, SCH 60, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS |
| Pipe Type | Seamless, Welded, ERW, EFW, Fabricated, LSAW |
| Form | Round, Square, Rectangular, Hydraulic |
| Length | Single Random, Double Random, Cut Length, Custom Length |
| End | Plain End, Beveled End, Threaded End |
| Surface Finish | Annealed & Pickled (AP), Bright Annealed (BA), Polished, Mill Finish |
| Testing | PMI Test, Hydrostatic Test, Ultrasonic Test, Eddy Current Test, Flaring Test, Flattening Test, Third Party Inspection |
| Marking | Grade, Size, Heat No., Manufacturer's Logo |
| Packing | Plastic End Caps, Bundles, Wooden Boxes, Wooden Pallets, Export Worthy Packing |
Chemical Composition
C
0.05 – 0.15
Carbon
Mn
1.0 Max
Manganese
S
0.015 Max
Sulfur
Si
1.0 Max
Silicon
Cr
20.0 – 24.0
Chromium
Mo
8.0 – 10.0
Molybdenum
Ni
44.5 Min
Nickel
Cu
0.5 Max
Copper
Ti
0.6 Max
Titanium
Al
0.8 – 1.5
Aluminium
B
0.006 Max
Boron
Co
10.0 – 15.0
Cobalt
Fe
3.0 Max
Iron
Equivalent Grades
STD
Alloy 617
Standard
UNS
N06617
UNS
W.NR
2.4663
Werkstoff No.
Mechanical & Physical Properties
8.1 g/cm³
Density
1411°C (2571°F)
Melting Point
550 MPa / 80,000 Psi
Ultimate Tensile Strength
205 MPa / 30,000 Psi
Yield Strength (0.2% Offset)
30%
Elongation
Recent Export Deliveries
🇸🇦
Saudi Aramco Total
Al Jubail, Saudi Arabia
304 SS Round Bars, 50mm OD, ASTM A276
Delivered in 7 days
🇺🇸
Hess Corporation
New York City, USA
SS 304 Hex Bars, 40mm A/F, Cold Drawn
Delivered in 14 days
🇬🇧
Shell PLC
London, United Kingdom
304 SS Flat Bars, 100×20mm, Bright Finish
Delivered in 14 days
🇦🇪
ADNOC
Abu Dhabi, UAE
304 SS Square Bars, 40mm, Forged Grade
Delivered in 5 days
🇿🇦
Sasol Limited
Johannesburg, South Africa
SS 304 Hollow Bars, 80mm OD × 20mm wall
Delivered in 21 days
🇩🇪
BASF SE
Ludwigshafen, Germany
304 SS Round Bars 25–100mm, EN 10204 3.2
Delivered in 18 days
Availability of Inconel Pipes
| Inconel 602CA Pipe | Inconel 600 Pipe |
| Inconel 601 Pipe | Inconel 617 Pipe |
| Inconel 625 Pipe | Inconel 718 Pipe |
| Inconel 725 Pipe | Inconel X-750 Pipe |
Latest Prices of Pipes
Multinox INC offers Pipes at one of the most competitive prices in India. Request the latest Pipes Pricelist using the contact form here.
